X22-7.4-M-860

Delivery:

Payment:

Means of Payment

For your convenience, we accept multiple payment methods in USD, including PayPal, Credit Card, and wire transfer.

RFQ (Request for Quotations)

It is recommended to request for quotations to get the latest prices and inventories about the part.
Our sales will reply to your request by email within 24 hours.

IMPORTANT NOTICE

1. You’ll receive an order information email in your inbox. (Please remember to check the spam folder if you didn’t hear from us).
2. Since inventories and prices may fluctuate to some extent, the sales manager is going to reconfirm the order and let you know if there are any updates.

Specification	X22-7.4-M1-860-	X22-12-M1-860-
Rated Voltage	DC7.4V	DC12.0V
Voltage Range	DC6.0V–8.4V	DC9.0V–13.0V
Stalling Torque	7.0 N·m @ 7.4V	7.0 N·m @ 12V
Rated Torque	2.2 N·m @ 7.4V	2.5 N·m @ 12V
Stalling Current	7.50 A	6.00 A
Rated Current	1.98 A	1.68 A
No-load Speed	0.15 sec/60° @ 7.4V12V	0.14 sec/60° @ 12V
Rated Speed	0.21 sec/60° @ 7.4V	0.20 sec/60° @ 12V
Working Frequency	1520 µs / 333 Hz	Same
Default Travel Angle	100°–200° (500–2500 µs)	Same
Temperature Range	-10°C to +65°C	Same
Ball Bearing	6 BB	6 BB
Case Dimensions	45 mm × 22 mm × 52 mm ±0.2 mm	Same
Weight	128 g ±10%	Same
