S3399 24-Port Gigabit Stackable Managed Switch – Specifications Table

Parameter Category	Specification Details
Model Number	S3399
Product Type	24-Port Gigabit Stackable L3 Managed Switch
Hardware
RJ-45 Copper Ports	24 x 10/100/1000BASE-T Gigabit Ethernet
SFP Fiber Uplink Ports	4 x 1G/10G SFP+ Slots (Dedicated, not combo)
Console Port	1 x RJ-45 Console Port (CLI Management)
USB Port	1 x USB Type-A (For configuration file/ firmware upload)
Stacking Ports	Optional Stacking Module or via 10G SFP+ ports (Vendor-dependent)
Performance
Switching Capacity	128 Gbps
Forwarding Rate	95.2 Mpps
Packet Buffer Memory	12 MB
MAC Address Table	16K entries
Software Features (L2/L3)
Management	Web UI (HTTP/HTTPS), CLI (Telnet/SSH), SNMP (v1/v2c/v3), RMON
Layer 2 Features	STP/RSTP/MSTP, VLAN (802.1Q, Voice VLAN, MAC-based), LLDP, Link Aggregation (LACP, 8 groups max), IGMP Snooping v1/v2/v3, Port Mirroring, Loopback Detection
Layer 3 Features	Static Routing, RIP v1/v2, OSPF (limited), PIM-SM/DM for IPv4, VRRP for gateway redundancy
QoS	802.1p COS, DSCP, 8 queues per port, Rate Limiting (Ingress/Egress)
Security	802.1X (Port/MAC-based), ACL (IPv4/IPv6), RADIUS/TACACS+ Authentication, DHCP Snooping, IP Source Guard, Dynamic ARP Inspection, DoS Attack Prevention
Hardware Reliability
Power Supply	Dual, Hot-Swappable Power Supply Slots (PSU typically not included)
Fan Module	Redundant, Hot-Swappable Fan Tray
Physical
Dimensions (W x D x H)	440 x 260 x 44 mm (19-inch Rack Mountable, 1U Height)
Power Input	100-240V AC, 50/60 Hz (Dependent on installed PSU)
Operating Temperature	0°C to 50°C (32°F to 122°F)
Operating Humidity	10% to 90% non-condensing
Mean Time Between Failures (MTBF)	> 200,000 hours
Certifications	CE, FCC, RoHS, REACH
