S2744-09

Delivery:

Payment:

Means of Payment

For your convenience, we accept multiple payment methods in USD, including PayPal, Credit Card, and wire transfer.

RFQ (Request for Quotations)

It is recommended to request for quotations to get the latest prices and inventories about the part.
Our sales will reply to your request by email within 24 hours.

IMPORTANT NOTICE

1. You’ll receive an order information email in your inbox. (Please remember to check the spam folder if you didn’t hear from us).
2. Since inventories and prices may fluctuate to some extent, the sales manager is going to reconfirm the order and let you know if there are any updates.

S2744-09 LCD Module – Technical Specifications (Estimated)

Parameter Category	Specification	Details / Notes
Model Number	S2744-09
Display Type	a-Si TFT-LCD	Amorphous Silicon Thin-Film Transistor Liquid Crystal Display.
Touchscreen	Integrated Projected Capacitive (P-Cap)	Likely 10-point multi-touch. Glass-on-glass construction.
Screen Size	27.0 inches	Measured diagonally.
Aspect Ratio	16:9	Standard for 4K UHD.
Active Area	~596.74 (W) × 335.66 (H) mm	Standard dimensions for a 27″ 16:9 panel.
Resolution	3840 × 2160 (4K UHD)	Most likely scenario. High pixel density for sharp details.
Pixel Pitch	~0.1554 × 0.1554 mm
Brightness	350 – 600 cd/m² (Typ.)	High brightness is common for touch-enabled professional displays.
Contrast Ratio	1000:1 / 1200:1 (Typ.)
Viewing Angle	178° / 178° (Typ.) (H/V)	Certainly uses IPS (In-Plane Switching) technology.
Display Colors	16.7M / 1.07B (8-bit + FRC)	May use FRC to achieve higher color depth.
Color Gamut	Possibly >72% NTSC / sRGB	Suitable for color-critical touch applications.
Surface Treatment	Anti-Glare, Anti-Fingerprint	Oleophobic coating is common on capacitive touchscreens. Optical Bonding is likely to reduce parallax and internal reflection.
Response Time	5ms – 8ms (GtG)
Refresh Rate	60Hz
Backlight Type	W-LED
Lifetime	30,000 – 50,000 hours (Typ.)
Signal Interface	eDP (Embedded DisplayPort)	Essential for handling 4K resolution data bandwidth.
Touch Interface	USB (HID)	The HID protocol allows for plug-and-play compatibility on most operating systems (Windows, Linux, Android).
Input Voltage	5.0V or 12V (Typ.)	Powers both the LCD and touch controller.
Power Consumption	Higher than S2744-08	Due to the integrated touch controller and potential optical bonding.
Operating Conditions	Temperature: 0 to 50 °C	Capacitive touch can be affected by thick gloves and excessive moisture.
Storage Conditions	Temperature: -20 to 60 °C
Mechanical Outline	~620.0 (W) × 360.0 (H) × ~18.0 (D) mm	Thicker than -08 model due to the added capacitive glass layer and bonding.
Weight	Heavier than S2744-08	Due to the added glass and components.
Mounting	VESA Mount Compatible	Likely 100mm x 100mm pattern.
