S16765-2181

The S16765-2181 is a high-sensitivity, low-noise CMOS linear image sensor designed for precision spectral analysis and optical measurement applications. Featuring Hamamatsu’s advanced back-illuminated technology, this sensor delivers exceptional quantum efficiency and signal-to-noise ratio across a broad spectral range.

Delivery:

Payment:

Parameter	Specification	Unit
Model Number	S16765-2181	–
Device Type	Back-Illuminated CMOS Linear Sensor	–
Array Configuration	2048 × 1	pixels
Pixel Size	14 × 200	μm²
Pixel Pitch	14	μm
Active Area	28.672 × 0.2	mm²
Spectral Range	200-1000	nm
Quantum Efficiency	>80% (400-800nm)	–
Output Channels	Dual analog outputs	–
Data Rate	Up to 20	MHz
Dynamic Range	72	dB
Read Noise	<15	e⁻
Dark Current	<0.5	mV/ms
Saturation Capacity	750,000	e⁻
Power Supply	3.3 (Analog), 1.8 (Digital)	V
Power Consumption	120	mW
Operating Temperature	-5 to +60	°C
Package Type	24-pin ceramic DIP	–
Dimensions	38.0 × 9.5 × 4.5	mm
