S15611-10

The S15611-10 is a high-performance, low-noise CMOS linear image sensor designed for precision spectral analysis and optical measurement applications. Featuring Hamamatsu’s advanced pixel architecture, this sensor delivers exceptional sensitivity and dynamic range for demanding scientific and industrial applications.

Delivery:

Payment:

Parameter	Specification	Unit
Model Number	S15611-10	–
Device Type	CMOS Linear Image Sensor	–
Array Configuration	1024 × 1	pixels
Pixel Size	14 × 200	μm²
Pixel Pitch	14	μm
Active Area	14.336 × 0.2	mm²
Spectral Range	200-1000	nm
Peak Sensitivity	550	nm
Output Type	Analog voltage	–
Data Rate	10	MHz
Dynamic Range	70	dB
Read Noise	<20	e⁻
Dark Current	<0.5	mV/ms
Saturation Output	1.2	V
Power Supply	3.3 (Analog), 1.8 (Digital)	V
Power Consumption	120	mW
Operating Temperature	-20 to +70	°C
Package Type	24-pin ceramic DIP	–
Dimensions	30.0 × 9.5 × 4.5	mm
