The S1336-8BK is a high-sensitivity silicon photodiode designed for precision light detection in the visible to near-infrared spectrum. Featuring a large active area and excellent linearity, it is widely used in analytical instruments, medical devices, and industrial sensors.
Means of Payment
For your convenience, we accept multiple payment methods in USD, including PayPal, Credit Card, and wire transfer.
RFQ (Request for Quotations)
It is recommended to request for quotations to get the latest prices and inventories about the part.
Our sales will reply to your request by email within 24 hours.
IMPORTANT NOTICE
1. You’ll receive an order information email in your inbox. (Please remember to check the spam folder if you didn’t hear from us).
2. Since inventories and prices may fluctuate to some extent, the sales manager is going to reconfirm the order and let you know if there are any updates.
| Parameter | Specification | Unit |
|---|---|---|
| Model Number | S1336-8BK | – |
| Type | Silicon PIN Photodiode | – |
| Spectral Range | 320–1100 | nm |
| Active Area | 1.13 × 1.13 (1.28 mm²) | mm² |
| Peak Sensitivity | 960 | nm |
| Responsivity | 0.62 @ 960nm | A/W |
| Dark Current | ≤ 0.5 (typ. @ 5V bias) | nA |
| Rise Time | 0.5 | μs |
| Capacitance | 4 | pF |
| Breakdown Voltage | 30 | V |
| Operating Voltage | 0–25 | V |
| Output Type | Analog current | – |
| Package | Resin mold, lead type | – |
| Dimensions | 4.5 × 4.5 × 2.1 | mm |
| Weight | ~0.5 | g |
