Product Overview: The R5108 is a compact, configurable safety relay designed to implement safety functions up to PL e / SIL 3. It provides flexible integration for emergency stops, safety gates, and two-hand control systems in a modular DIN-rail format.
| Category | Parameter | Specification |
|---|---|---|
| General | Model Number | R5108 |
| Product Type | Programmable Safety Relay (PSR) | |
| Safety Rating | PL e (ISO 13849-1), SIL 3 (IEC 61508/IEC 62061) | |
| Modularity | Configurable with expandable I/O modules | |
| Input Channels | Number of Safety Inputs | 8 (Dual-channel, configurable) |
| Input Types | Dry contact, OSSD (PNP/NAMUR), Analog (0-10V/4-20mA) | |
| Diagnostics | Cross-circuit detection, short-to-ground monitoring | |
| Output Channels | Number of Safety Outputs | 3 (Semiconductor), 2 (Electromechanical Relay – FORCE guided) |
| Output Ratings | 2A @ 24VDC (relay), 0.5A @ 24VDC (semiconductor) | |
| Dual Channel Outputs | Yes (for monitoring) | |
| Functionality | Configurable Functions | E-Stop, Safety Gate, Two-Hand Control, Mode Selector, Muting |
| Programming | USB or Ethernet via safety-configurator software | |
| Response Time | < 20 ms | |
| Electrical | Supply Voltage | 24 VDC (-15% / +20%) |
| Current Consumption | < 100 mA (典型) | |
| Test Pulse Output | Yes (for input device monitoring) | |
| Physical & Environmental | Mounting | DIN Rail (35mm) |
| Operating Temperature | -25°C to +60°C | |
| Ingress Protection | IP20 | |
| Connection | Removable screw terminal blocks | |
| Certifications | Standards | UL 61496, TÜV, CE, cULus |
