H16200P-50

Delivery:

Payment:

Means of Payment

For your convenience, we accept multiple payment methods in USD, including PayPal, Credit Card, and wire transfer.

RFQ (Request for Quotations)

It is recommended to request for quotations to get the latest prices and inventories about the part.
Our sales will reply to your request by email within 24 hours.

IMPORTANT NOTICE

1. You’ll receive an order information email in your inbox. (Please remember to check the spam folder if you didn’t hear from us).
2. Since inventories and prices may fluctuate to some extent, the sales manager is going to reconfirm the order and let you know if there are any updates.

Product Specification Sheet: Model H16200P-50

Category	Specification	Details
General Information	Model Number	H16200P-50
	Product Name	Multi-Axis Machine Controller (Panel Mount)
	Product Line	H16200 Series (Axis Control)
	Variant	8-Axis Central Controller, Panel Mount Version
	Note	The “P” suffix denotes the Panel Mount form factor with IP65 front.
Performance Specifications	Control Axes	8 axes of synchronized motion
	Command Interface	EtherCAT® (100+ nodes), PROFINET IRT, OPC UA
	Processing	Dual-core processor, 1GB RAM
	Programming	IEC 61131-3, C++, Custom function blocks
	Integrated I/O	32 Digital Inputs, 24 Digital Outputs, 4 Analog Inputs, 2 Analog Outputs
	Expansion Slots	2 slots for additional I/O or communication modules
	Power Input	24 VDC (18-32 VDC range) or 100-240 VAC
	Power Consumption	45W (typical)
	Data Storage	8GB non-volatile memory for data logging
Mechanical & Environmental	Mounting	Panel Mount (IP65 front when installed)
	Panel Cutout	195 mm x 145 mm
	Operating Temperature	0°C to +60°C
	Front Protection Rating	IP65 (Dust-tight, protected against water jets)
	Rear Protection Rating	IP20 (For control cabinet use)
	Dimensions (W x H x D)	200 mm x 150 mm x 85 mm
Compliance & Certification	EMC	CE, FCC Class A, UL Listed
	Standards	RoHS 3, REACH Compliant
